DATA LOGGER

“NOVA” DATALOGGER – 8 CHANNEL

INTRODUCTION :
“NOVA/WEATHER” Datalogger  is   Microprocessor based system specially designed  for  Datalogging of  various  Area  including  Weather   Monitoring, Oceanography,   Industrial   Parameter   Logging, Specific Test Datalogging etc etc.This  Datalogger is having versatile application with useof different type of sensors.

SPECIAL FEATURES:
  • Very low power consumption using CMOS IC’s.
  • Long Battery back-up time (Works for appx. 7 days on 12V, 7 Ah battery).
  • Minimum power up programming.
  • Built-in sensor interface.
  • Atmospheric discharge, transient protection provided.
  • 20 Key, membrane type key board for easy programming and setting.
  • LCD Display, real time clock calendar, serial output port (RS-232C) for connection to Computer & parallel interface to printer or memory module battery operation with provision for mains adapter. Software for retrieval of data from memory module provided.
  • 256 K memory module – 2 Nos.
  • Memory reader card.
  • 12 V Maintenance free battery – 2 Nos.
  • Battery charger.
DATALOGGER – 8 CHANNEL

TECHNICAL SPECIFICATION:

The Datalogger is microprocessor based weather monitoring system with built-in clock and calendar.
  • Power Requirement – 12 V DC
  • Outputs
- One parallelport for connecting memory module or 80 column dot matrix printer (Centronics compatible).
- One serial port for serial data transfer (RS-232).
- One Alphanumeric 2 line liquid crystal display for indicating real time data and time and calendar.
  • Input Channel – 8
  • Analog to Digital Conversion – 12 bit double slope ADC.
  • Built-in signal conditioners for Sensors.
OPTIONALS:
  • Weather proof enclosure.
  • Solar panel with charger circuitry.
  • Computer with Printer.
  • Laptop Computer.
  • 80/132 column. Dot Matrix printer.

SENSORS AVAILABLE OPTIONALLY:
  • Wind Speed sensor (Anemometer).
  • Wind Direction sensor.
  • Air, Soil, Water Temperature sensors.
  • Relative Humidity sensor.
  • Atmospheric Pressure Sensor (Barometric).
  • Rainfall sensor (Tipping Bucket type).
  • Solar Radiation sensor.
  • Water Evaporation sensor.
  • Soil Moisture sensor.
  • Water Current sensor.
  • Water level sensor.
  • Albedo Meter sensor.
  • Net Radiation sensor.
  • Any specific application based sensor can be developed & supply.
