| Temperature Range |
Above ambient to 450 Deg.C/600 Deg.C |
| Temperature Control |
By Microprocessor Based Auto Tune 4 Digit PID Controller. |
| Display |
Set Value Indication [SV] Digital WindowProcess Value Indication [PV] Digital Window. |
| Resolution |
0.1 Deg.C |
| Reference Indicator Controller : |
| By Calibrated PID Controller having universal input for RTD or various type of thermocouples or millivolt or milliamp selectableby front feather touch keys. |
| Timer |
A Digital Timer pre-settable upto 999 minutes provided and after elapse of pre-setTime the unit will be automatically Off. |
| Accuracy |
+/- 0.1 % FS. |
| Stability |
+/- 0.5 Deg.C. |
| Heating Time |
From ambient to max.within 30 to 45 Min. |
| Cooling Time |
Max.60 Min.to bring down the temp.upto approx.100 Deg.C by built-in force air cooling. |
| Wattage/Power Consumption : Approx.1200 W or as required. |
| Well Depth |
120mm or suitable nearest length. |
| Insertion Tube |
To suit ½” & ¼”, 3/8” probes. 1 no. each. Or 6,8,10,15,20mm. |
| Line Voltage |
220V AC Single phase 50Hz +/- 5%. |
